Our roll to roll printer machine delivers amazing printing through UV innovation, broadening applications and a stable electric system. It efficiently transfers design from a digital file onto materials such as banner, coated PP, vinyl, PET film & PVC film etc. It is widely used in the textile, signage and apparel industry with intricate patterns and vibrant colors. An anti-collision unit enhances operational safety by detecting obstacles, has real-time alerts, preventing accidents and protecting both equipment and operator. It reduces the risk of damage, improving overall machine reliability. boosts productivity and enhances safety.
Model: Thunderjet AQ1602UVZ
| Model | Thunderjet AQ1602UVZ |
|---|---|
| Print Head | 1~2 Epson I3200 U1 print heads |
| Technology | Drop-On-Dempnd Piezo with Variable Dot |
| Curing System | Dual water cooling LED UV lamps |
| Ink | UV Flexible ink |
| Colors Config. | 1xKCMY; W+1xKCMY |
| Ink Supply System | Bulk ink supply system + white ink recirculation system |
| Ink Tank | 1000ml |
| Printing Width | Max. 1600mm |
| Media Type | Banner, Coated PP, Vinyl, Backlit textile, PVCfilm, PET film…... |
| Roll Diameter | Max. 300mm |
| Roll Weight | Max. 50kgs |
| Core Diameter | 3 in (76.2mm) or 2 in (50.8) |
| Printing Speed Mode | Resolution - Color(1H) - CWC - CWKW |
| Printing Speed Draft | 720x1200dpi - 10.5m2/h - 5.2m2/h - 1.6m2/h |
| Printing Speed Production | 720x1200dpi - 8.5m2/h - 3.4m2/h |
| Printing Speed High-res | 720x1800dpi - 6m2/h - 3.1m2/h - 1m2/h |
| Printing Speed Photo | 720x1800dpi - 5m2/h - 2m2/h |
| Data Interface | External: Ethernet; Internal: Fiber Optical |
| Working Environment | Temp.23ºC~29ºC, Humidity:50%~80% |
| Software | FlexiPRINT / ONYX (Optional) + GZ Printer Manager |
| Power | Single phase, 50Hz/AC, 220V±10%, 5A (Printer + UV Controller) |
| Installed Size | LxWxH(mm): 2783 x 767 x 1558 |
| G.W. / N.W. | 290 kgs / 190kgs |
Print Head
The Epson i3200 U1 print head receives digital image data from the computer and translates it into machine understandable form. It consists of the nozzle to eject tiny droplets onto the media and precisely controls them to form the desired image. This head’s advanced technology ensures precise ink control.
Curing System
The roll to roll printer has dual water cooling LED UV lamps that emit UV light to cure the ink on the media. It prevents overheating and adjusts lamp power settings to accommodate different ink & substrate types. Rapidly dries which leads to instant output production. The cooling system provides uniform ink delivery across the entire print width that gives excellent adhesion and long-lasting durability. Rapidly dries the output production and prevents overheating.
Piezo With Variable Dot
This printer has drop on demand piezo with variable dot technology that ejects the ink drops onto the media precisely based on the requirements. This fine-tuned control produces detailed output, rapid printing versatility and achieving superior image reproduction. The variable dot allows to adjust droplet size dynamically for smooth gradients and accurate color transitions. Piezo technology provides excellent ink control without heat in long production runs.
Ink Supply System
The roll to roll printer features bulk ink supply system with 1000ml has prolonged print runs, reduced downtime and cost-effectiveness due to larger ink reservoirs. The white ink stirring system prevents pigment settling, reducing clogs, collectively enhancing productivity and reducing maintenance needs. Supports continuous printing and consistent flow for high-volume production environments. The bulk ink system avoids frequent refilling interruptions and maintains uniform color density.
RIP Software
The FlexiPRINT/Onyx RIP software with GZ printer manager gives consistent color reproduction, support for various file formats enhances workflow compatibility and reduces material waste. These advanced features result in superior image quality and Automated workflow options streamline production.
