The heavy duty CNC router works by computerized or automated control for the process of cutting, drilling, milling, carving with the help of sharp tools and etching in various materials such as acrylic, plastic, MDF, aluminum & wood etc. It has many configurations, a dedicated CNC controller, spindle, servo motor, linear guides and a workspace table. This machine can process the cutting tool with accurate angles with different bits such as straight, rabbeting, chamfer and beading etc.
Model: MW103-ATC
| Model | MW103-ATC | MW-1530-ATC |
|---|---|---|
| Spindle | HSD 6 HP ER32 | HSD 6 HP ER32 |
| Inverter | Delta | Delta |
| Max. Width | 1270mm | 1500mm |
| Max. Length | 2540mm | 3000mm |
| Z Clearance | 150 mm (Max.) | 150 mm (Max.) |
| Table | T-Slot/Vacuum Bed | T-Slot/Vacuum Bed |
| ATC | Yes | Yes |
| Controller | Googol Tech | Googol Tech |
| Max. Weight | 80 Kg / sqm on bearings | 80 Kg / sqm on bearings |
| Cutting Material | Acrylic, Plastic, MDF, Aluminum, Wood, Brass, Copper | Acrylic, Plastic, MDF, Aluminum, Wood, Brass, Copper |
| Axis | 4 | 4 |
| Spindle Speed | 18000 / 24000 rpm | 18000 / 24000 rpm |
| Spindle Cooler | Fan / Air Cooled | Fan / Air Cooled |
| Speed | 20 - 30 m/min | 20 - 30 m/min |
| Axis Motor | Hybrid Servo | Yaskawa Servo Drive & Motor |
| Brush Feet | Yes | Yes |
| Dust Cover | Yes | Yes |
| Print Interface | USB 2.0 + Networking | USB 2.0 + Networking |
| Power Specification | AC 220 V / 380 V / 5KW | AC 220 V / 380 V / 5KW |
| Operational Environment | Temperature: 20°C - 30°C Humidly: 20% to 80% | Temperature: 20°C - 30°C Humidly: 20% to 80% |
| Software | ArtCAM / EnRoute / Type 3 | ArtCAM / EnRoute / Type 3 |
| Dimension & Weight Machine | L3765 x W1760 x H220mm 1.5 Ton | L3765 x W1760 x H220mm 1.5 Ton |
| Dimension & Weight Package | L3900 x W1900 x H1350mm 1.6 Ton | L3900 x W1900 x H1350mm 1.6 Ton |
Delta Inverter
It is a power conversion device that regulates the voltage and ensures inverter load capability. Delivers high efficiency for a wider range of power in both synchronization and non-synchronization techniques.
EZ Controller
It controls the heavy duty CNC router device, programmable controller, servo drive & motors. It drives the system in the sequential control actions to complete the machining process and boosts for high production.
HSD Spindle 10 HP
It is composed of a heavy-duty motor to run the machine at different speeds. It can control the actions by the numerical control system such as start & stop the operation and rotate at a specific frequency.
Bearing Guide Rail
It controls the rotational motion, reduces friction, guides the CNC router machine to linear motion with high precision and reduces the misalignment of the shaft.
CAD/CAM Software
The CAD/CAM software takes the design parts from the file to the production line with utmost precision and efficiency. Creating the geometric code, send to the controller which directs the machine in the instructed path and enhances the productivity needs with precise machining needs.
