Roll To Roll UV LED Printer

Better Printing Output & Flexibilty

The roll to roll UV LED printer delivers a highly desirable printing with the combination of quality, speed and value. It is ideally suited for a productive & profitable business and a perfect tool for producing flexible graphics in the media such as banner, backlit, PET and backlit & reflective film etc. This wide-format print technology uses UV curable ink along with many other advanced features to meet the business demands ever more effectively. It allows for a broader scope of print applications, minimal heat output because of LEDs, enables printing on the heat-sensitive material by limited heat generation and very stable calibration.

Model: GZM3200KM

Functions & Features

The dual water cooling UV LED lamp cure ink quickly after it has done the operation that transfers the LED energy to dry the printed image. It is capable of producing sharper contrast without any degradation of intensity, generates a consistent output and has less energy consumption.
In a roll to roll UV LED printer, the positive purging system acts as a cleaning system, making the cleaning operation simpler and giving fine printing details. It eliminates the printing deficiency, less need for rework that would waste ink & media, leads to significant power savings and higher ROI in the long run.
It contains two air shafts, two dance bars & pinch rollers that roll on the media while moving and press against the media surface for smooth movement. Ensures the proper pressure is applied to the material and handles the tension to give accurate media delivery in every print.

Specifications

Model	GZM3200KM
Print Head	4 Konica 1024i
Head Configuration	1XCMYK
Curing System	LED UV curing System
Ink	UV curable ink
Colors	Standard: KCMY
Ink Supply System	Negative pressure system + White ink stirring system
Cleaning System	Positive Purging System
Servo System	Panasonic A6 400W Servo System
Media System	2 Air Shafts + 2 dancer bars + pinch rollers
Media Type	Backlit, Banner, Canvas, Backlit Film, Reflective Film, Tarpaulin, Backlit Textile, Vinyl, Wall coverings, PP, PET.
Media Width	Max. 3200mm
Printing Width	Max. 3200mm
Printing Speed	Draft Mode: 540X1080dpi - 36.5m2/h
Printing Speed	Production Mode: 540X1440dpi - 28.6m2/h
Printing Speed	Quality Mode: 540X1080dpi - 19.4m2/h
Printing Speed	High Precision Mode: 540X1440dpi - 14.4m2/h
Data Interface	External: USB2.0; Internal: SCSI cable
Working Environment	Temperature: 20°C-28°C, Humidity: 40%-70%
Software	PhotoPRINT UV Edition (Optional Onyx)+GZ Printer Manager
Image Format	Bitmap, TIF, Quark Xpress, JPEG, EPS, PDF
Power	Single-phase, 50/60Hz, AC220V+10%, 10A, Regulator: 10kVA
Dimension	4790x1193x1520mm(Installed)/5930x1150x1740mm(Packed)
Weight(N.W./G.W.)	1035kgs/1335kgs

Major Components

Negative Pressure
System

Air Shaft & Dancer
Bar

Huge LED Backlight
Panel

Konica 1024i
Print Heads

Led UV Lamp &
Anti Collision UNIT

Panasonic A6 400W
Servo System

Components of The Machine

Konica Print Head
The 4-8 Konica print head with four color configuration such as KCMY has a maximum ink drop size up to 13 PL. It prints on various media, has impressive throughput, reduces ink usage and greatly improves operational flexibility.

PhotoPRINT
Roll to roll UV LED printer adopts PhotoPRint as RIP software that assists to create the print files, makes the raster image as a digital image processing and can track the workflow efficiently. It automates the operating instructions from the start to end of printing, highly interactive and user-friendly software.

Negative Pressure System
The negative pressure system & white ink stirring system is the versatile printing system that enables the print head to supply the ink with proper pressure and balance the pressure between the ink tank & head. It drops the accurate ink onto the media for optimal color density, smoother color gradation and lowers the ink being used.

Servo System
The Panasonic 400W A6 servo system moves the carriage accurately on the print substrate and designed to present perfect printing quality by driving it more stably. It runs with minimum noise, prevents the media deformation and maintains the machinery perfect(maybe) over the life of the printer from damage risk.

Backlight Panel
The huge LED backlight panel is equipped to check the results after the printing which avoids output with wrinkles and reduces the rejection rate. It solves the problem of maintaining the quality and enables a more desirable end-product. Adoption of this innovative print solution expands the reach of the industry smartly due to its versatility, energy efficiency and cost-effectiveness.
