An eco solvent printing machine uses advanced technology that utilizes environmentally friendly solvent inks, reducing harmful emissions and promoting sustainability. The key features include vibrant color reproduction, output details clarity and compatibility with a wide range of media. It is suitable for indoor and outdoor applications. The environmentally responsible printing solution and combining performance with ecological consciousness and precise automation features enhance user-friendliness. It offers numerous advantages, eco-friendly solvent inks emit volatile organic compounds (VOCs).
Model: AQ1601S / AQ1602S
| Model | AQ1601S | AQ1602S |
|---|---|---|
| Print Head | Epson i3200 E1 print heads | Dual Epson i3200 E1 print heads |
| Technology | Drop-On-Demand Piezo with Variable Dot | // |
| Ink | EPI2-2 years durability eco solvent ink | // |
| Color Config. | K.C.Y.M. | // |
| Ink Supply System | Bulk ink supply system with ink cartridges | // |
| Ink Tank | 1000ml | // |
| Printing Width | Max.1600mm | // |
| Media Type | Banner, Coated PP, Vinyl, PVC film | // |
| Roll Diameter | Max. 300mm | // |
| Roll Weight | Max. 50kgs | // |
| Core Diameter | 3in (76.2mm) or 2in (50.8mm) | // |
| Printing Speed Draft | 360x1200dpi - 30m2/h | 360x1200dpi - 60m2/h |
| Printing Speed Production | 360x1800dpi - 22m2/h | 360x1800dpi - 43m2/h |
| Printing Speed Hi-resolution | 720x1200dpi - 15m2/h | 720x1200dpi - 30m2/h |
| Printing Speed Photo | 720x1800dpi - 10m2/h | 720x1800dpi - 21m2/h |
| Data Interface | USB 2.0 | // |
| Working Environment | Temp.23ºC~29ºC, Humidity: 50%~80% | // |
| Software | PhotoPRINT / Onyx (Optional)... + GZ Printer Manager | // |
| Power | Single phase, 50Hz / AC, 220V±10%, 6.7A (Printer)+8.18A(IR Dryer) | // |
| Installed Size | LxWxH(mm): 2783x767x1558 | // |
| G.W./N.W. | 290kgs/190kgs | // |
Print Head
The dual Epson i3200 E1 print head employs piezo variable dot technology and exceptional reliability ensures consistent output over time and minimizing downtime. The compatibility with various inks & media makes creative possibilities.
Piezo With Variable Dot
The drop on demand piezo with variable dot technology precisely controls ink droplet ejection. It allows the head to vary droplet sizes, producing different levels of color intensity and image detail. This results in smooth gradients, sharper edges, reducing ink consumption and achieving exception output across photography to fine art. It provides stable ink jetting for the high volume of production runs from the first print to the last. The precise placement of the droplet avoids overspray for the well-defined graphics. Suitable for detailed images and compatible with multiple ink types & substrates.
Bulk Ink Supply System
The bulk ink supply system conjunction with the ink cartridge feeds ink directly to the head. The extended print runs without constant cartridge replacements, contribute to reduced waste and lower ink cost. The eco solvent printing machine is economically viable for high-volume production and delivers optimal digital printing performance. It has balanced ink flow and assists in maintaining consistent color output throughout the printing sessions. Designed to monitor the ink levels easily so the operators can plan to refill in advance and avoid sudden stoppages.
IR Drying Unit
The intelligent IR dryer accelerates ink curing, drying instantly and optimizing the process without overheating. It delivers the output fast, increases production, efficient results and minimizes energy consumption. It enhances color saturation, detail sharpness, reducing waiting times, improves output’s visual appeal and increases production speed. The temperature control has the ability to adapt to different ink loads and diverse material thicknesses, so it prevents ink cracking or discoloration. Reducing the moisture retention maintains surface smoothness and enhances the overall workflow.
RIP Software
PhotoPRINT is a powerful RIP software that optimizes image processing and layout for superior output. Enables precise control over printing parameters and accurate color reproduction. Its user-friendly facilitates easy customization, previewing of prints and enhancing workflow efficiency. It supports various file formats and the software transforms digital design into vibrant.
