Our industrial roll to roll UV printer machine is designed for the continuous processing of materials such as banner, coated PP, vinyl, backlite, PVC and PET film etc. It features a precise feeding mechanism that facilitates uninterrupted printing on rolls of varying widths & lengths. Applications are versatile including signage, vehicle wraps, interior decoration and other customized products. It empowers businesses to produce large-format and long runs with versatility that makes it valuable for the digital printing industry. This design improves the reliability, performance and lifespan of the equipment.
Model: Thunderjet AC1802UV
| Model | Thunderjet AC1802UV |
|---|---|
| Print Head | 1~2 Epson I3200 U1 print heads |
| Technology | Dron-On-Demond Piezo with Variable Dot |
| Curing System | Dual water cooling LED UV lamps |
| Ink | UV Flexible ink |
| Colors Config. | 2xKCMY; 1xKCMY+W; W+1xKCMY+V |
| Ink Supply System | Bulk ink supply system + white ink recirculation system |
| Ink Tank | 1000ml |
| Printing Width | Max. 1800mm |
| Media Type | Banner, Coated PP, Vinyl, Backlit textile, PVC film, PET film…... |
| Roll Diameter | Max. 300mm |
| Roll Weight | Max. 50kgs |
| Core Diameter | 3 in (76.2mm) or 2 in (50.8) |
| Printing Speed Mode | Resolution - 1xKCYM - 2xKCYM |
| Printing Speed Draft | 720x1200dpi - 11.5m2/h - 20m2/h |
| Printing Speed Production | 720x1200dpi - 9.5m2/h - 18m2/h |
| Printing Speed High-res | 720x1800dpi - 7m2/h - 14m2/h |
| Printing Speed Photo | 720x1800dpi - 6m2/h - 12m2/h |
| Data Interface | USB 2.0 |
| Working Environment | Temp.23ºC~29ºC, Humidity:50%~80% |
| Software | FlexiPRINT Mini UV / ONYX (Optional) + GZ control console |
| Power | Single phase, 50Hz/AC, 220V±10%, 5A (Printer + UV Controller) |
| Packed / Installed Size | LxWxH(mm): 3330 x 1100 x 750 / 3126 x 924 x 1396 |
| G.W. / N.W. | 384kgs / 280kgs |
Print Head
The Epson i3200 U1 print head provides high-resolution capabilities for sharp and detailed prints. It allows for versatility, optimal print quality ensuring vibrant and accurate colors. These advanced technologies result in achieving efficient and top-notch printing results. The advanced nozzle structure gives uniform droplet placement with reduced banding and color variation. It has excellent adhesion, stability on operation and durability on multiple substrates.
Curing System
The industrial roll to roll UV printer has dual water cooling LED UV lamps that ensure uniform & efficient curing of UV inks on the media surface. It maintains constant lamp temperature, preventing overheating and higher lamp longevity. It also provides cost-effectiveness due to its long lifespan, best performance and modular design for easy maintenance in the UV printer.
Piezo With Variable Dot
Drop on demand piezo with variable dot technology allows precise control of droplet size and results in sharp details and smooth gradients. The versatility of adjusting droplet sizes for different printing needs, accurate droplet ejection, reducing misprints and delivering exceptional output. This advanced printing technology leads to image clarity by dynamically controlling droplet volume. Achieves smooth tonal transitions, consistent color density and fine text reproduction.
Ink Supply System
The bulk ink supply system with 1000ml has advantages such as extended print runs and avoids downtime for ink replacement. This process reduces operational costs by using larger ink reservoirs. The white ink recirculation system prevents pigment settling, reducing the risk of clogs and giving vibrant color output.
RIP Software
The PhotoPRINT/Onyx RIP software with GZ control console processes digital image files. It interprets any complex data and converts it into a format that the machine can understand. It automates workflows, facilitating efficient production, precise image processing and accurately colored prints. The precise calibration maintains consistent output across different substrates. Supports multiple file formats, efficient job queuing and has real-time monitoring.
