The digital fabric printing machine transforms the world of the textile industry with advanced computer technology that prints designs onto the fabric directly. This process allows for intricate patterns and precise details giving unprecedented creative freedom. The printer translates the digital design into high-resolution outputs, providing a quicker turnaround and reducing material waste. It helps to deliver customization and on-demand production. This machine has reshaped the way fabrics are produced and assists all independent designers.
Model: BPI-1800
| Model | BPI-1800 |
|---|---|
| Print Head | Two Epson I3200 E1 print head with 3200 nozzles |
| Printing Method | Drop-On-Demond Piezo with Variable Dot |
| Printing Color | 4 Color (syan, Magenta, Yellow, Black) |
| Print Head Height Control | 1.5mm 12.5mm Low / High |
| Printing Speed Draft | 360x1200dpi - 60m2/h |
| Printing Speed Production | 360x1800dpi - 43m2/h |
| Printing Speed High-res | 720x1200dpi - 30m2/h |
| Printing Speed Photo | 720x1800dpi - 21m2/h |
| Maximum Reolution | 1080DPI |
| Media Size | Maximum Media Thickness: 1.0mm (0.039in.) |
| Media Diameter | 2inch or 3inch |
| Ink Feeding System | Cartridge (220m1 per Color) |
| Printing Precision Level | 0.3% or 0.3mm |
| Head Cleaning | Automatic and/or Manual |
| Interface | Ethernet 10 Base-T |
| Weight | 580kgs |
| Operational | Power on-Temperature: 16ºC~24ºC / Humidity:40~65% - Power off-Temperature: 10ºC~30ºC / Humidity:20~60% |
| Power Resource | Direct dye sublimation heater: AC220V, 1phase+N+PE, 16A, 50/60Hz |
| Dimension | 2998mm(W) x 886mm(D) x 1262mm (H) |
| Operational Environment | Temperature 10ºC~32ºC Humidity:20~80% |
| Ink Type | Disperse dye ink (Sublimation Ink) |
| Media Type | Polyester |
Print Head
The Epson i3200 print head is designed to deliver fine details by ensuring reliable ink delivery and contributing to overall efficiency. It avoids clogging due to efficient design and allows for consistent & vibrant output. Has prolonged printhead life and top-notch printing performance.
Piezo With Variable Dot
The digital fabric printing machine has drop on demand piezo with a variable dot is a printing technology that creates precise droplets of ink only when needed and enhances image accuracy. This feature optimizes print quality for various substrates and different resolutions. The output results have smooth gradients with reduced ink consumption.
Pinch Roller
This machine has pinch roller serves by a pressure mechanism that provides a consistent feeding of media. It prevents slippage of material and accurate alignment to maintain print quality. Also, provides stable & uniform feed and precisely produces the digital image onto the chosen substrate. It gives constant pressure across the media and ensures smooth material movement during printing. Adapts to diverse media thicknesses and textures and avoids the risk of wrinkling or stretching without misalignment.
Capping System
The capping station efficiently maintains the print head performance and extends the head lifespan by ensuring consistent ink flow. This system creates an airtight seal around the head to protect it from dust and exposure to environmental air. It assists to operate smoothly without any ink-related issues. Prevents the nozzle drying and ink clogging during idle periods of the printing machine. It seals the print head securely, maintains optimal moisture levels, automatic ink circulation and reduced exposure to contaminants.
RIP Software
PhotoPRINT is a versatile user-friendly RIP software which is widely used in the digital printing industry. It efficiently handles complex image files and is a reliable choice for producing stunning visuals. Has precise control over color calibration to ensure accurate prints every time. This integrated software monitors multiple jobs simultaneously without output errors. Enhancing overall print quality in various printing environments.
