UV Roll to Roll Printer

Prints That Define Excellence

The UV roll to roll printer provides multi-application printing and contains a strong body with a varnish option. It uses flexible UV ink that offers durability in flexible substrates. It’s designed to withstand stretching and deformations without wrinkles, cracking or peelings. It cures quickly under UV light, allowing for fast production speeds. It is commonly used for application on materials such as banner, coater PP, vinyl, backlit and PVC film etc. It provides exact smooth gradation, resistance to abrasion and making it suitable for various demanding requirements. An anti-collision unit acts as a safety feature that utilizes sensors to detect obstacles or obstructions.

Model: AQ1800UV

Functions & Features

A multi-layer printing application involves the process of printing multiple layers such as 2, 3, 4 & 5 layers on a substrate to achieve vibrant texture. The printer is commonly used in many industrial applications to create smooth visual appeal and enables the production of complex designs & patterns with a high level of detail.
The UV roll to roll printer has a capping and wiping system with one pass wiper speeds up the print head cleaning and protects it from drying out or clogging. This capping process ensures the nozzles remain free of dried ink and the wiping mechanism removes the excess of ink or debris from the head's surface. It helps maintain consistent print quality, prolongs the lifespan of the head and efficient printing operations.
The water cooling platen circulates through channels within the platen, regulates its temperature. It helps to print on a wide range of materials, print for heat-sensitive substrate and manage the heat generated during the process. It ensures stable operation, prevents substrate distortion and benefits with optimal results.

Specifications

Model	BPI1800UV
Print Head	3~4 Epson i3200 Print Heads
Technology	Drop-On-Demond Piezo with Variable Dot
Curing System	Dual water cooling LED UV lamps
Ink	UV Flexible Ink
Color Config.	KCYM; KCYM + W
Ink Supply System	Aluminum sub tanks with heaters + White ink stirring system
Ink Tank	2500ml
Printing Width	Max.1800mm
Media Type	Banner, Coated PP, Vinyl, Backlit textile, PVC film, PET film ......
Roll Diameter?	Max. 300mm
Roll Weight	Max. 50kgs
Core Diameter	3 in (76.2mm) or 2 in (50.8mm)
Printing Speed	Draft - 720x1200 dpi - 46.8m2/h
Printing Speed	Production - 720x1200 dpi - 41m2/h
Printing Speed	High-res - 720x1800 dpi - 32.5m2/h
Printing Speed	Photo - 720x1800 dpi - 23m2/h
Data Interface	USB 2.0
Working Environment	Temp. 23ºC ~ 29ºC, Humidity:50%~80%
Software	PhotoPRINT Mini UV / Onyx (Optional).. + GZ control console
Power	Single phase, 50Hz /AC, 220V+10%, 5A (Printer+UV Controller)
Packed/installed Size	LxWxH(mm): 3700x1100x1750 / 3540x1249x1506
G.W./ N.W.	700kgs/ 500kgs

Major Components

Epson i3200 U1
Head

Capping & Wiping System

Intelligent Heating Unit

Multi-layer Printing Application

Water Cooling Platen

White Ink RecirculationSystem

Components of The Machine

Print Head

The Epson i3200 U1 print head has multiple color configurations to print on the material. This mechanism expels droplets of ink onto the substrate resulting in high-resolution prints. It incorporates advanced nozzle technology for accurate color reproduction with fine details.

Piezo Variable Dot
The UV roll to roll printer has piezo variable dot greyscale technology that controls the size of ink droplets ejected from the print head. It enables the creation of different dot sizes within an image and produces a wider range of tones & gradients. It gives smoother transitions and enhanced high-quality prints for applications.

Dual Water Cooling LED UV Lamps
The dual water cooling LED UV lamp has cooling technology to regulate the temperature and cure the ink on the media surface. It maintains consistent curing performance, prevents overheating and ensures proper adhesion of UV inks on different substrates.

Bulk Ink Supply System

The UV roll to roll printer has a bulk ink supply system that efficiently delivers a large volume of ink to the print head and reduces the requirement for frequent cartridge changes. The white ink recirculation system prevents clogging of white ink which is used for vibrant print on dark media. It increases productivity by reducing downtime for ink replacement and provides continuous & reliable operations.

RIP Software

FlexiPRINT/Onyx as RIP software assists in converting digital design files into printable formats and simplifies workflow optimization. It supports a broader range of file formats, facilitates seamless communication between software & machine and provides precise output for various applications.

Sample Images
