Large Format Flatbed Printer

Meets The Printing Innovation Precisely

The large format flatbed printer allows printing on a wide variety of substrates such as acrylic, foam board, PVC board, glass and ceramic tile etc. The UV curable ink has minimal time to spread out into the material, yields impressively accurate color details, strong finish and is resistant to fading or weathering. The automatic media height detector unit in the flatbed printer uses sensors to identify the type, size and placement of materials which helps to adjust print settings accordingly for optimized printing. It reduces the need for manual adjustments and maintains an ideal print head-to-media distance for consistent prints.

Model: H3220GN

Functions & Features

The large format flatbed printer is equipped with a 6 zones platen with media alignment pins that offers precise processing across various material sizes & types, preventing shifting or wrinkling during printing. It ensures accurate positioning of the material, allows consistent prints. It has the capability to handle diverse media, contributing to production efficiency.
The linear motor coupled with metal grating & dual linear guide provides precise print head movement, serves as a guide and facilitates smooth & controlled movement. This component assists in resulting in sharp & detailed end products on various materials.
The gantry control is achieved through a combination of linear motor and dual linear guides. These two are responsible for controlling the gantry's movement, allowing for synchronized movement of the print head. It assists in producing high-quality output with accurate results while accommodating different printing requirements.
The large format flatbed printer has an anti-collision unit that contains sensors to detect obstacles or potential collisions within the printing area. Upon detection, it triggers the automatic response such as stopping or adjusting the head to prevent damage to the equipment or materials.

Specifications

Model	H3220GN
Print Head	5~8 Ricoh Gen6 print heads
Resolution	726x900~726x2400 dpi
Curing System	Water cooling LED UV curing lamps
Ink	UV curable ink
Color Configuration	2xKCMY1+1xWW
Color Configuration	2xKCMY1+2xWW
Color Configuration	3xKCMY1+1xWW
Color Configuration	3xKCMY1+2xWW
Color Configuration	4xKCMY
Ink Supply System	GnTek negative pressure system and white ink stirring & circulation system
Ink Tank	2500ml
Media Thickness	Max. 100mm
Media Type	Acrylic, Aluminum sheet, Foam board, PVC board, Leather, Glass, Wood, Ceramic tile, etc
Table Size	3260 x 2160mm
Printing Size	Max. 3200 x 2000mm
Printing Speed Mode	Resolution - Feather - 3xKCMY - 4xKCMY
Printing Speed Draft	726x900dpi - Gradient - 69m2/h - 84m2/h
Printing Speed Production	726x1200dpi - Gradient - 54m2/h -67m2/h
Printing Speed Hi-resolution	726x900dpi - Uniform - 39m2/h - 49m2/h
Printing Speed Photo	726x1200dpi - Uniform - 31m2/h - 39m2/h
Data Interface	External: USB 3.0; Internal: Fiber Optical
Working Environment	Temp.20 C~30 C, Humidity:35%~65%
Software	PhotoPRINT + GZ control console
Power	Single phase, 50/60Hz, AC220V 10%, 13A(Printer + UV Controller) + 21A (Vacuum system)
Packed / Installed Size	LxWxH(mm): 5770 x 3600 x 2000 / 5400 x 3030 x 1500
G.W. / N.W.	3290kgs / 2091kgs

Major Components

Ricoh Print Head

AC Servo Motor

Automatic Media Height Detector

Linear Motion _ Dual Linear Guides

Negative Pressure System

Six Zone Platen

Water Cooling LED UV Lamp

Anti Collision Unit

Components of The Machine

Print Head
The Ricoh Gen6 print heads eject tiny ink droplets precisely onto the printing surface for high-resolution prints. The head is designed for long-lasting performance, requires minimal maintenance and variable dot size capabilities offer versatility. It is also compatible with various inks and media types, which helps for efficient digital printing.

Negative Pressure System
The Gntek negative pressure system with white ink stirring and circulation system maintains consistent ink pressure, preventing nozzle clogs. The white ink system stirs and circulates ink, resulting in uniform & vibrant prints. It’s valuable for applications requiring precise results on various materials.

Variable Dot Technology
The drop on demand piezo variable dot technology of the flatbed printer offers significant features, control over ink droplet formation and size. Variable dot sizes cater to a range of print requirements, including fine text, smooth gradients and vibrant graphics. It conserves ink, cost-effective, efficient printing for excellent quality.

Curing System
The dual water cooling LED UV curing system of the flatbed printer is an invaluable addition to modern digital printing that provides ideal curing temperatures for durable prints. The dual lamp gives comprehensive curing coverage, speeding up production.

RIP Software
The PhotoPRINT RIP software with GZ control console optimizes print jobs by processing and managing them efficiently. It ensures accurate color management with vibrant output and offers features like nesting, control over layout and color accuracy. Supports various printer models, has high compatibility, versatility and advanced workflow capability streamlines production.

Sample Images
