The digital paper printer is a modernized machine that converts digital files into transfer paper. It is essential for the industry which requires speed, precision and versatility, to produce vibrant graphics. The anti-wrinkle platen operates securely holding the media, wrinkle-free media feeding. It avoids the risk of wrinkles or creases in different types of paper media and assures distortion-free prints. The media handling system efficiently feeds print media, smooth media transport, adjustable tension control to prevent jams and various media type support. It handles the media for accurate print, detects media irregularities and makes real-time adjustments.
Model: Apsaras G5
| Model | Apsaras G5 |
|---|---|
| Print Head | 8 x Epson I3200 A1 print heads |
| Ink | GS high density sublimation transfer ink certified by OEKO TEX with ''ECO PASSPORT'' |
| Colors Config. | K.C.Y.M; Optional 8 colors: K.C.Y.M + S1. S2. S3. S4 |
| Ink Supply System | Bulk ink supply system with ink cartridge |
| Printing Width | Up to 1950mm |
| Media Type | Transfer Paper (30 to 100gsm) |
| Feeder | Feeding: 2000m; Taking up: 1000m |
| Roll Diameter | Up to 350mm |
| Drying System | Intelligent sectionable control IR dryer |
| Printing Speed Draft | 720x600dpi - 363m2/h |
| Printing Speed Production | 720x600dpi - 317m2/h |
| Printing Speed High-res | 720x1200dpi - 182m2/h |
| Printing Speed Photo | 720x1200dpi - 159m2/h |
| Data Interface | External: Ethernet; Internal: Fiber Optical |
| Working Environment | Temp.18ºC~30ºC, Humidity:35%~65% |
| Software | neoStampa Delta + GZ Printer Manager |
| Power | Single phase, 5Hz/AC, 220V±10%, 5.5A (Printer) + 28A (IR Dryer) |
| Packed / Installed Size | LxWxH(mm): 3760 x 1100 x 1940 / 3600 x 1280 x 1550 |
| G.W. / N.W. | 960kgs / 705kgs |
Print Head
The Epson i3200 A1 print head with piezo variable dot technology ejects ink to print on the substrates. The head processes the digital data into printed output with high resolution. It allows for sharper details with a broader color gamut, vivid colors and enables smoother gradients.
Ink Supply System
The bulk ink supply system of digital paper printer has huge storage ink in large reservoirs of 5 liters. It is connected to the head through a tube to supply the ink for the operation. It precisely flows the ink to the print head, sensors continuously monitor the reservoir and extended printing without frequent cartridge replacements.
Drying System
An intelligent sectionable control IR heater uses advanced technology that cures the ink on the media surface. This system dynamically adjusts the heat output to optimize drying, preventing overheating and delivering consistent print quality.
Piezo Variable Dot
The process of piezo variable dot technology generates the pressure to eject ink droplets to print on the media. The size of the droplets can be controlled and gives smooth gradients with fine details. As the head moves across substrates, it deposits variable sized ink dots to create quality output.
RIP Software
neoStamps Delta RIP software with GZ printer manager has easy to use interface that makes the printer understandable format from the input file. Ultimately, the software streamlines the process, enhances image quality, offers control over processing parameters and flexibility to meet various printing needs.
