Our Co2 laser cutting machine is a versatile solution to the various industries with the right equipment and also that can satisfy their needs for processing a variety of materials. This machine characteristically outperforms the competition associated with using a laser engraver or cutter machine and offering precision that can benefit your organization. It can execute different operations depending on how the operator configures their settings such as laser cutting, engraving & marking with different functioning conditions and each process lends itself to fulfill various industrial applications.
Model: BPI-1309
| Model | BPI-1309 |
|---|---|
| Working Area | 1300*900mm |
| Working Table | Blade or Honeycomb |
| Speed Cutting | 50mm/s |
| Speed Engraving | 300mm/s to 400mm/s |
| Laser Type | Co2 Glass laser tube |
| Laser Power | 80W/100W/130W/150W |
| Material | Acrylic / Engraving Sheets /Vinear / Wood |
| Positioning Accuracy | ±0.05mm(without red dot) |
| Image Format Supported | BMP,PLT,AI,DXF,etc |
| Cooling System | Constant temperature water cooling and protecting system |
| Power Supply | AC 110-220±10%, 50-60Hz |
| Working Temperature | 0-45°C |
| Working Humidity | 5%-95% |
| Optional Equipment | Air Blower, Hollow Strip Table or Honeycomb Cutting table. |
| Software | Corel Draw, AutoCad, Adobe Illustrator |
| Focus | Manual |
| Connectivity Interface | USB 2.0 Online & Offline / U DISK |
| Power Specification | 220V AC 15 AMP |
| Operational Environment | Temperature 10°c - 32°c Humidity 20% - 80% |
| Operating System | Windows 7 64bit |
The Co2 laser cutting machine has a DSP control system as controlling software to manage the setting of cutting power, angle and number of passes. Also, can set the production speed consistently depending on the material density and thickness.The Co2 laser delivers a fast initial piercing time, the ability to apply finish to a product and does not require post-machining treatments to finish it. The machine can handle repeated cuts on different materials while maintaining accuracy. Its programmable settings allow operators to adjust parameters quickly for each job and the system ensures smooth operation even during long production runs.
The stepper motor drives the laser beam path accurately along with fast cutting and greatly reduces the maintenance required. The chiller satisfies the cooling requirements of the components and makes the CO2 laser cutting very cost-effective. It allows the machine to move in exact increments, making it possible to perform precise positioning tasks repeatedly. The controlled motion reduces strain on the system and maintains stability.
